• Brand : Optimuz
• Model : S6266
• Dimension : 176cm x 100cm x 72cm
• Weight : 300g
• Power : 5V DC ± 10% @ 450mA

PERFORMANCE :

• Light Source : Aimer:617nm LED White 6500K
• Illumination : 625nm LEDs
• Fiel of View : 39°(H) x 25°(V)
• Roll : 0-360°
• Pith : ±65° or Greater
• Yaw : ±60° or Greater
• Print Contrast : 25% minimum reflective difference

DECODE CAPABILITY :

1D – UPC/EAN, UPC/EAN with supplementals, Bookland, EAN, ISSN:

• UCC Coupon Extend Code;
• GS1-128, Code 128, ISBT 128;
• Code 39, Code 39 Full ASCII, Trioptic Code 39, Code 32;
• Code 93, Code 11;
• Matrix 2 of 5, interleaved 2 of 5, Discrete 2 of 5, Codebar, MSI;
• Chinese 2 of 5, GS1 data bar Variants, Korean 3 of 5, ISBT Concat;

2D – PDF417, MicroPDF417, CompositeCodes, TLC-39:

• Data Matrix, Maxicode, QR code, Micro QR, Aztec;
• Motion Tolerances : Up to 25in/63.5cm per second;
• Interfaces Supported : USB:HID Keyboard(default mode), COM Port Emulation;
• Minimum Resolution : SR:Code 39 4.8mil;UPC 60% 5mil,PDF417 5mil,Datamatrix 7.5mil.

REGULATORY :

• Electrical Safety : UL60950-1 2nd ed,CSA C22.2 No.60950-1 2nd ed,EN60950-1/IEC60950-1 2nd ed;
• LED Safety : IEC/EN60825-1:2001. IEC/EN62471:2006
• EMI/RFI : FCC Part 15 class B, ICES-003 Class B, EN55022 Class B, EN55024.

USER ENVIRONMENT :

• Operating Temperature : 0°C to 40°C;
• Strong Temperature : -40°C to 70°C;
• Humidity : 5% to 95% non-condensing;
• Drop Spec : Withstands Multiple 6 Ft. Drops to Concrete;
• Ambient Light Immunity : Immune to normal indoor lighting up to 1600Lux;
• Immune to Sunlight : Upto 86,000Lux.
